Sandal Wood Absolute Solvent Extraction Unit

Name: Sandal Wood Absolute Solvent Extraction Unit
Brand: BEST ENGINEERING TECHNOLOGIES
Price: 16000000.0 INR
Availability: InStock

Price 16000000.0 INR/ Pair

Get a Price/Quote

MOQ : 1 Pair

Sandal Wood Absolute Solvent Extraction Unit Specification

Product Type
Sandal Wood Absolute Solvent Extraction Unit

General Use
Extraction of sandalwood absolute and essential oil from sandalwood chips using solvent extraction technology

Capacity
500 kg/batch (customizable as per requirement)

Material
Stainless Steel 304/316

Type
Industrial Extraction Unit

Weight (kg)
Approx. 6000 kg

Computerized
Yes

Automatic
Fully Automatic

Control System
PLC based HMI Touch Screen Control Panel

Voltage
380-415 V, 3 Phase, 50/60 Hz

Motor
Flame Proof Motor, 5-7.5 kW (Depending on configuration)

Dimension (L*W*H)
9000 mm x 6000 mm x 7000 mm (Custom on capacity)

Feature
Energy efficient, explosion-proof, easy operation, CIP system, high yield

Color
Metallic Silver (SS Polished Finish)

Vacuum System
Industrial grade vacuum pump for efficient solvent removal

Batch Time
8-12 hours (depending on feed and process parameters)

Residual Solvent Content in Product
< 1 ppm (meets international export standards)

Solvent Recovery Efficiency
Above 98%

Heating System
Steam jacketed vessel with digital temperature control

Safety Features
Pressure release valves, vacuum and pressure sensors, safety interlock systems

Operator Requirement
1-2 personnel per shift (for monitoring and auxiliary support)

Utility Consumption
Steam, Water, Electricity-detailed as per plant design

Solvent Handling System
Explosive-proof solvent handling and recovery system

Installation Area Required
Approx. 75-100 sq.m.

Condensation System
Double-stage Condenser for maximum recovery

Extraction Method
Solvent Extraction via Agitated Reaction Vessel

Operating Temperature
50C to 95C (adjustable)

Application Industries
Essential Oil Extraction, Fragrance, Perfumery, Ayurvedic, and Herbal Oil Processing

About Sandal Wood Absolute Solvent Extraction Unit

Purchase the Sandal Wood Absolute Solvent Extraction Unit, the finest choice for professional extraction needs. Crafted from high-quality stainless steel with explosion-proof features, this masterpiece delivers superior performance ensuring over 97% solvent recovery efficiency. With fully automated PLC controls and energy-efficient systems, it's engineered for both safety and ease. This affordable solution is ending soon-secure your enlightened investment while supplies last. Perfect for extracting sandalwood absolute and essential oils, it's the definitive extraction unit for large-scale production, blending precision with innovation and reliability.

Commercial Masterpiece with Extra Features

The Sandal Wood Absolute Solvent Extraction Unit is widely used for extracting high-purity sandalwood absolute and essential oil, making it ideal for commercial perfumeries, aromatherapy suppliers, and cosmetic manufacturers. Renowned for its robust commercial uses, it processes sandalwood chips, bark, and aromatic woods efficiently. Extra features include an integrated automatic CIP system, flame-proof motor, high-efficiency condenser, and customizable capacity, ensuring seamless operation and consistently enlightened results in industrial-scale extraction environments.

Certifications, Supply, and Lowest Price Offer

This extraction unit is certified for industrial safety and operational excellence, meeting stringent standards for explosion-proof operation and energy efficiency. Our export capability guarantees regular supply and availability, with the lowest price offer to help reduce your expenditure. We supply from principal FOB ports for smooth global trade, combining competitive pricing with reliability. Don't miss this opportunity-purchase now to ensure affordable access to one of the most advanced extraction systems on the market.

FAQ's of Sandal Wood Absolute Solvent Extraction Unit:

Q: How does the Sandal Wood Absolute Solvent Extraction Unit operate?

A: This extraction unit uses food-grade hexane or ethanol to extract sandalwood absolute and essential oil from sandalwood chips and aromatic woods. Its fully automated system ensures efficient processing with a working pressure of 0.3-0.5 MPa and temperature control between 35-60C.

Q: What safety features are included in the extraction unit?

A: The unit comes with explosion-proof electricals, pressure relief valves, an emergency stop function, and a flame-proof motor for maximum operator safety during production.

Q: When should the CIP system be utilized?

A: The integrated automatic CIP (Clean-In-Place) system should be used after each extraction batch or as required by operational cleanliness standards, ensuring optimal hygiene and system efficiency.

Q: Where can this extraction unit be installed?

A: As a skid-mounted and modular machine, installation is versatile and simple. It is suitable for industrial settings, including extraction plants, fragrance factories, and manufacturing facilities dealing with essential oils or herbal extracts.

Q: What are the main benefits for commercial production?

A: Businesses gain from high yield, energy efficiency, customizable batch capacities, user-friendly PLC touch-screen controls, and robust safety mechanisms, making this extraction unit a superior investment for commercial operations.
